Ceramic Blow Bars with Chrome Cast Iron – Xtra Long Life Solution (BCX700)

This composite solution offers exceptional wear resistance, with performance improvements of up to 180% compared to the BC650 model.

Designed for the most demanding environments, the BCX700 delivers enhanced durability and extended service life, helping reduce maintenance costs and optimize crushing efficiency.

Chrome Cast Iron + Ceramic Blow Bars (BCC650)

These chrome cast iron blow bars with ceramic inserts are designed to process highly abrasive materials, such as those commonly found in gravel pits.

Thanks to this technology, wear resistance can be improved by up to 100% compared to the BC650 model, providing extended service life and increased efficiency in the most demanding environments

Martensitic Steel + Ceramic Blow Bars – Xtra Long Life Solution (BMX550)

This alloy delivers an exceptional improvement in wear resistance, offering up to 200% greater performance compared to the BMC550.

Its optimized composition ensures extended service life, even under demanding crushing conditions, helping to reduce maintenance costs and downtime.

Martensitic Steel + Ceramic Blow Bars (BMC550)

This option is ideal for crushers used in recycling facilities. It is specially designed for the recycling of reinforced concrete, including steel reinforcement and other foreign materials. Its ceramic inserts provide exceptional wear resistance.

Thanks to its robustness and wear resistance, this solution can provide up to 100% longer service life compared to the BM550, making it a high-performance and durable solution for demanding recycling environments.

Martensitic Steel Blow Bars (BM550)

With a hardness ranging from 500 to 580 HB, these blow bars are designed for crushing applications involving low to moderate abrasion.

They offer excellent impact resistance and are ideally suited to less demanding applications where the processed materials are not highly abrasive, while still requiring high durability.

Manganese Steel Blow Bars (CCX)

Our manganese steel blow bars are designed to provide good wear resistance in crushing applications involving soft to medium-hard rock, such as limestone.

Their high manganese content enables these blow bars to effectively absorb impacts while maintaining their hardness and toughness, extending their service life in low-abrasion and less demanding crushing conditions.

Chrome Cast Iron Blow Bars (BC650)

These blow bars are manufactured from chrome cast iron, without ceramic inserts, and are designed for applications where no uncrushable materials are present.

With a high hardness ranging from 650 to 700 HB, these blow bars provide good wear resistance, ensuring optimal performance in demanding crushing conditions.

Steel Impact Plates (type Hardox)

We can manufacture impact plates from flame-cut steel, such as Hardox, offering high wear resistance.

Whether for an urgent order or for a crusher experiencing low wear, we can manufacture impact plates from flame-cut steel, such as Hardox, offering excellent wear resistance.

Chrome Cast Iron Plates (with or without Ceramic Inserts)

Suitable for applications where no uncrushable materials are present and the material being processed is relatively abrasive, such as in gravel pits.

Chrome Cast Iron Plate

Martensitic Steel Impact Plates (with or without Ceramic Inserts)

Designed for the recycling of concrete and/or inert construction materials containing steel reinforcement and uncrushable materials, such as manhole covers and similar items.

Manganese Steel Impact Plates

Primarily used in applications involving the crushing of soft to medium-hard rocks, such as limestone.

Manganese Steel Impact Plate

Bimetallic Liners

We also offer side liners made from two different steel grades, reinforced on one side for significantly extended service life. However, these liners require a minimum material thickness to be manufactured.

Side Liners

Side liners for impact crushers, manufactured from high wear-resistant cut steel (such as Hardox 450) or chrome cast steel, depending on the application.

We also manufacture custom liners (side liners, discharge liners or other specific designs), with or without threads or custom heads, to perfectly match your requirements and installation.

Wear Bars

Wear bars are components located in the feed chute of a crusher, just before the blow bars. Their role is to protect the machine against abrasion caused by the material falling freely before entering the crushing chamber. We also supply these components.

Impact Screens / Monobloc Impact Walls

The monobloc, also known as an impact wall, is a large cast component used in impact crushers. Unlike impact plates, it is designed as a single solid piece. Its role is to absorb the impact of materials projected at high speed by the rotor. As the material strikes the monobloc, it is fragmented by impact, allowing it to be efficiently crushed into smaller pieces.
